Exodraft EFC18 Control Unit

With its 9 steps, the fan speed can be adjusted depending on whether you are starting a fire, refueling, or maintaining the fire.

The EFC18 is an electronic control unit that connects to your chimney fan to give you control over the fan.

The control unit comes with a temperature sensor, which is installed under the chimney fan. It sends a signal to the control unit when the temperature reaches 20, 40, or 80 °C (depending on the setting), and it turns off the fan after 45 minutes. This ensures complete combustion of all combustible materials in the stove.



On the front of the compact control unit, there is a knob and a small display that shows which of the 9 steps the chimney fan is set to.

Features

Operation

Manual

Compatible with

Small and Medium-Sized Chimney Fans

Aesthetics

Compact Design

Technology

9-Step Button

Technical Specifications



Height (mm)

85

Length (mm)

85

Depth (mm)

32,5

Max. load

1,2 A

Fuse

T 1,25 AH

Voltage

230 V AC, 50 Hz

Sorrunding temperature

-50 ºC – +400 ºC

Ambient temperature

0 ºC – +40 ºC

Density Class

IP 30

Material

ABS

Colour

White
